Display information
76
% Err Fields: Shows a calculated number showing the percentage of all
fields since the last reset that contained at least one error.
Black Events: Shows when a black frame has occurred within the video
image. Settings configured in the CONFIG > Measurement Settings menu.
Frozen Events: Shows when a frozen frame has occurred within the video
image. Settings configured in the CONFIG > Measurement Settings menu.
Changed Since Reset: Indicates if either the F1 or F2 AP CRC values have
changed since the last reset.
Frozen: This readout only appears when you press the CAPTURE button.
It indicates that errors are being gathered, but are not being displayed on the
Status page. This state is useful for looking at EDH (Error Detection and
Handling) CRC (Cyclic Redundancy Check) values on live video.
CMPST elements of the Video Session display. These elements are visible when
Composite 2A or 2B is the selected signal.
Input: Shows the selected input source.
Format: Shows the format of the input signal; either PAL or NTSC.
Signal Lock: Indicates whether the signal is locked or unlocked.
Sync AFC Speed: Shows the Sync AFC Speed setting: Fast or Slow.
DC Restore: Shows the DC Restore setting: Fast, Slow, or Off.
NTSC Setup: Shows the NTSC Setup setting: Off or On.
