Getting started
6
Instrument options. Your instrument may have been ordered with one or more
options. (See Table 5.)
You can check which options are on the instrument after it is powered on by
performing the following steps.
1. Press the CONFIG button on the front panel.
2. Use the General knob to navigate to Utilities.
3. Press the right arrow button to navigate to the Utilities submenu and select
View Instrument Options. The menu box on the right side of the display
shows the installed options.

Table 5: Instrument options

Option
Video 2SDI
3G
4K
CPS
3D
GEN
Instrument
model Description
WVR8200, Adds support for second SDI board in
WVR8300 Slot 2 of the instrument rear panel. With
this option, this instrument can monitor
up to four SDI inputs. This option is not
compatible with Option CPS.
WVR8200, Adds support for 3G-SDI signal formats.
WVR8300
WVR8200, Adds support for UHDTV1/4K signal
WVR8300 formats (requires Options 3G and 2SDI).
WVR8200, Adds support for Composite Analog Video
WVR8300 Monitoring; 2 composite Analog inputs;
passive loop-through. This option is not
compatible with Option 2SDI.
WVR8200 Adds Stereoscopic 3-D Video Monitoring
Capabilities (including Simultaneous Input
Monitoring (SIM) of dual SDI inputs and
synchronized left eye and right eye signals
monitoring (SyncVu™)).
WVR8200 Adds color bar and pathological signal
generator for SD/HD SDI. Option 3G
required for 3G-SDI support.
WVR8200 and WVR8300 User Manual
