To monitor alarms
WVR8200 and WVR8300 User Manual
4. Select the required services for the desired CC type and select the CC
channels and/or Text channels for which you want to trigger the CC Services
Missing Alarm.
5. For SDI Gamut display related alarms, select Gamut Thresholds and then
the desired gamut thresholds.
After defining and enabling alarms, you can quickly check if any error condition
exists by looking (or listening) for the notification you defined (text, icon, logging,
SNMP trap, beep). (See page 21, Status bar icons.) Selecting audible response
(Beep) or the Ground Closure output response can help you notice alarms that you
may miss if the notification is text or icon only. The latter can be used to drive a
light or audible alarm when one or more alarms are triggered. (See page 133, To
set allowed alarm responses.)
To check the condition of a specific alarm, press the STATUS button. In the
Status menu, select Display Type and then select Alarm Status. One or more of
the following appear:
Indicator
Disabled (gray)
OK (green)
Error (yellow)
Error (red)
NOTE.
To monitor alarms remotely, use a PC to monitor SNMP traps over the
Ethernet port (the PC must have SNMP trap service installed). Before SNMP
traps can be sent, you must enable and configure the instrument for SNMP control
using the Network Settings submenu of the Configuration menu.
Monitoring the SDI physical layer
Description
Alarm is not selected for reporting, but still
shows if the error is present.
Alarm is enabled for reporting and has not
detected errors for at least 5 seconds.
Alarm condition cleared for less than
5 seconds.
Alarm triggered now.
