Headphone volume and source adjustment

110
When line select is active an on screen, the display will show the Field/Frame and
Line Number that is currently selected. Use the left and right arrow keys to select
different fields, links or streams, depending on the format.
The Field readout can show All, F1, or F2 depending on the selected format
The Line readout can show the line number count for field or (frame)
depending on the format
In Dual Link format, select Link A and Link B by using the left and right
arrow keys
In 3G Level B format, select the virtual streams Strm 1 and Strm 2 by using
the left and right arrow keys
In UHD or 4K formats, V indicates Vertical lines and A indicates Active lines
Line Select mode can be active in only one tile at a time
You can change the measurement in that tile and remain in Line Select mode
You can also see which line is currently selected in the Picture mode or in a
field sweep waveform in another tile
NOTE.
Audio features require Option AD or DPE.
WARNING. To avoid damaging your hearing, always turn the volume down to the
minimum before you put on headphones, and then turn the volume up slowly.
The headphone jack is located on the front panel of your instrument. You can
adjust the volume to the headphones from the Audio menu.
1. Press the AUDIO button to show the audio display in a tile.
NOTE.
The headphone icon appears at the bottom of the Audio display.
2. Use the Horizontal knob to adjust the volume.
3. Adjust the headphone source by pressing the AUDIO button, selecting
Headphone Input, and then selecting the source you want.
