Closed caption (CC), Teletext, AFD, and Safe Area compliance

Your instrument can monitor for CC data (including V-Chip ratings) present in the
selected signal and display that data overlaid on the Picture display. (CEA 608
(VBI), CEA 608 (ANC), CEA (608/708), CEA 708, TeletextB (VBI), TeletextB
OP47 SDP (ANC), and TeletextB OP47 Multi (ANC) closed caption transports
are supported.
Your instrument can also display Safe Action and Safe Title graticules, allowing
you to monitor for incorrect placements of graphics, logos, and other branding
elements. This will help you ensure that those items do not obscure text or
essential action. SMPTE, ITU, and ARIB TR-B.4 standards are supported.
NOTE.
CC/Teletext format monitoring is tile specific. To simultaneously monitor
more than one format, select the appropriate settings in the desired tile.
Perform the following procedures before monitoring CC and Teletext.
1. From the CONFIG menu, select Aux Data Settings.
2. Select from the following CC types:
CEA 608 Settings (See page 179.)
CEA 708 Settings (See page 180, To configure CEA 708 settings.)
Teletext B Settings (See page 180, To configure Teletext B settings.)
To configure CEA 608 settings.
1. Select CEA608 Settings from the Aux Data Settings submenu.
2. Select CEA608 Required and then select Yes or No, depending on whether
you want to monitor for required settings.
3. Select CEA608 Transport, and then select from Auto, Line 21, S334
(RAW), or S334 (CDP). If you select Auto, the instrument will search for
any available transport.
4. Select VBI Mode, and then select Auto or Manual. If you select Manual, set
VBI Line Num using the General knob.
