Reference
Belden 1855A. Coax-Sub-Miniature Number of Coax: 1 RG Type:
Sub-miniature 59/U AWG: 23 Stranding: Solid Conductor Material: BC-Bare
Copper Insulation Material: Gas-injected FHDPE-Foam High Density
Polyethylene Outer Shield Material Trade Name: Duofoil: Outer Shield
Material: Aluminum Foil-Polyester Tape-Aluminum Foil/TC-Tinned Copper
Outer Jacket Material: PVC-Polyvinyl Chloride Plenum (Y/N): N Nom.
Characteristic Impedance: 75 ohm Applications: Video Cable, Precision
Video Cables for Analog and Digital Applications, Precision Video Cable for
Analog and Digital, Sub-Miniature, Precision Video Cable for Analog and
Digital, Sub-Miniature RG-59/U Type
Canare L-5CFB. Coax-Solid Copper Center Conductor; Foam PE Dielectric
Tinned Copper Braid + 100% Foil Shield Dielectric; 100% Sweep Tested;
Nominal O.D. in. (mm): .303 (7.7); PVC Jacket Thickness in. (mm): .043
(1.1)
Image 1000. Coax-Conductor size: nominal mm 1.0; Conductor material:
Copper, Plain; Dielectric material: Cellular PE; Inner Screen: Aluminium
Polyester Tape; Outer Screen: Tinned Copper Braid 95%; Jacket Material:
LSOH (PVC to special order); Nominal Diameter: mm 6.8; Cable weight:
kg/km 60.0; Impedance ohms (+/-1): 75.0 Capacitance (nominal): p/F/m 56.0
DC resistance max ohms/100m: 2.19 Velocity of propagation %: 83.0
