To set allowed alarm
responses
To set alarm responses
globally
WVR8200 and WVR8300 User Manual
This procedure allows you to select what type of alarm response you want for
each alarm category.
1. From the CONFIG menu, select Alarms.
2. Navigate to the alarm category that you want to configure. For example,
Video Format.
3. Note that the alarms in the category you select appear to the right as you
highlight the alarm category. Press SEL to display a table that allows you to
set the responses for individual alarms.
4. For each alarm listed in the table, select the box to place (or remove) an X
in the box under each response that you want enabled (or disabled) for that
alarm. (See page 132, Possible alarm responses.)
5. Navigate to highlight the Return box, and press the SEL button to return
to the Configuration menu.
Repeat these steps to configure other alarm categories.
This procedure allows you to set alarms for all alarm categories to the setting on
the global mask.
1. From the CONFIG menu, select Alarms.
2. Navigate to Set all Alarms to this Mask.
3. Press SEL to display a table for setting the allowed responses for alarm
settings to be applied to all alarm categories.
4. For each alarm listed in the table, select the box to place (or remove) an X
in the box under each response that you want enabled (or disabled) for that
alarm. (See page 132, Possible alarm responses.)
5. Navigate to highlight the Return box, and press the SEL button to return
to the Configuration menu.
Monitoring the SDI physical layer
133
