WVR8200 and WVR8300 User Manual
Table 6: Channel Mode versus Listening Modes (cont.)
Channel mode Listening mode
2/0 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
1/0 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
Main channel output function
Default to Stereo mode
Default to Stereo mode
Default to Stereo mode
Default to Stereo mode
2/0 channels
L+R
LCRS from 2/0 channels
3 Stereo from 2/0 channels
Phantom from 2/0 channels
Default to Mono mode
Default to Mono mode
Default to Mono mode
Default to Mono mode
Default to Mono mode
Mono center channel output
Default to Mono mode
Default to Mono mode
Default to Mono mode
Monitoring audio
177
