Remote front-panel control

Instrument online help

WVR8200 and WVR8300 User Manual
Control Element or Group
Configuration button
Up/Down/Left/Right arrow and SEL buttons
General knob
Vertical and Horizontal knobs
Power button
Display button
Main button
Other button
This instrument can be controlled remotely by the Tektronix WVR8RFP remote
front panel, an optional accessory. The remote front panel functions just like the
instrument front panel, with just a few differences. For detailed installation and
operation information, see the WVR8RFP Remote Front Panel Instructions.
When you press the HELP button on the front panel of your instrument, the
instrument online help is accessed. Use the instrument online help when you
have questions about buttons, features, operations, or anything else related to
your instrument. It is:
Context-sensitive. The topic displayed depends on what is displayed in the
active tile when the online help is selected or what control is operated after
help is selected.
Navigable. The Contents and Topic Selector panes, with links within the
topics, provide access to topics. (See Figure 4 on page 13.)
Getting acquainted with your instrument
Usage Procedures
Use to set parameters, view instrument
options, upgrade SW, and perform many
other tasks.
Use to navigate menus and select
parameters.
Use to navigate menus and adjust
parameters.
Use to position waveforms when displayed
in tiles or full-screen. When the Audio tile is
active, use the Horizontal knob to adjust the
headphone volume.
Press to turn the instrument on or off. Note
that this button does not remove power from
the mains.
Access to waveform, graticule, LCD backlight
intensity, display capture to USB, and Infinite
Persistence mode.
Access to Input Monitor Mode (Single,
Simultaneous, or UHD/4K), Multi-Input
display mode, SyncVu mode, SIM mode, 3D
input, and USB status.
(See page 61, LTC display.)
