Tic mark SD timing error (ns)
0 marks 0
1st 20
2nd 40
3rd 74
4th 148
1
Luma sample
2
Chroma sample
WVR8200 and WVR8300 User Manual

Figure 71: Determining transition intersections in the Lightning display

The + tic marks on the graticule indicate the following timing errors:
HD timing error (ns)
0
2
5
1 13.5
2 27
Checking chroma/luma delay (Lightning display)
1080p 50, 59.94, 60, 3Gbps (3 Gb/s
and dual link formats) timing error
(ns)
0
1
2.5
6.75
13.5
137
