Display information
90
BG Data: Indicates the binary group (BG) data value.
Wide Screen Signaling (WSS): Indicates if the WSS is present. The
supported formats include Composite PAL and 625-line SD. The WSS data is
displayed with the hexadecimal byte value and its description. WSS decoding
conforms to standard ITU-BT.1119-2.
Active Format Description (AFD): Indicates if the SMPTE 2016-1 and 3
Format for Active Format Description and Bar Data is present. The AFD
data is displayed with the hexadecimal byte value and its description. AFD
decoding conforms to standard SMPTE 2016 1-3.
Video Index Scanning B2-B0: Shows the Video Index Scanning System
information. Conforms to SMPTE RP186-2008 Class 1.1. Data Octet 1.
Scanning System provides information about the total number of lines, field
rate, and aspect ratio.
Video Index AFD/ARD B6-B3: Shows the Video Index binary value of Bits
6 to Bits 3 that are used to define the Active Format Descriptor. Conforms to
SMPTE RP186-2008 Class 1.1. or ARDSPEC 1. See the instrument online
help for a detailed description of codes: while the Aux Data Status display is
active in a tile, press the HELP button.
