xx
WVR8200 and WVR8300
Waveform Rasterizers, and
WVR8RFP Remote Front Panel
ZZZ
Service Manual
*P077039400*
077-0394-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WVR8300 and is the answer not in the manual?

Questions and answers

Related Manuals for Tektronix WVR8300

Summary of Contents for Tektronix WVR8300

  • Page 1 WVR8200 and WVR8300 Waveform Rasterizers, and WVR8RFP Remote Front Panel Service Manual *P077039400* 077-0394-00...

  • Page 3: Service Manual

    WVR8200 and WVR8300 Waveform Rasterizers, and WVR8RFP Remote Front Panel Service Manual www.tektronix.com 077-0394-00...
  • Page 4 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
  • Page 5 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

  • Page 7: Table Of Contents

    Audio Options AD and DPE ................Option EYE/PHY.................... Fan Control ....................Power Supply and Distribution................Adjustment Procedures Adjustments ....................... Required Equipment..................Procedures ....................Maintenance General Maintenance..................... Preventing ESD ....................Inspection and Cleaning..................Troubleshooting....................WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 8 Detailed Troubleshooting Procedures ..............4-10 Repackaging Instructions ..................4-22 Packaging ....................4-22 Shipping to the Service Center ................4-22 Replaceable Parts Replaceable Parts ....................Parts Ordering Information ................. Using the Replaceable Parts Lists................WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 9 Figure 5-1: Replaceable parts (standard) ..............Figure 5-2: Replaceable parts (standard) ..............Figure 5-3: Replaceable parts (options)................ Figure 5-4: Replaceable parts (WVR8RFP Remote Front Panel)......... 5-13 Figure 5-5: Analog audio breakout cable assembly ............5-14 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 10 Table 4-2: Internal inspection check list ............... Table 4-3: Required test equipment ................Table 4-4: Symptoms and causes ................Table 4-5: Main board secondary supplies ..............4-12 Table 4-6: Audio board secondary supplies ..............4-13 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 11: General Safety Summary

    Recharge batteries properly. Recharge batteries for the recommended charge cycle only. Use proper fuse. Use only the fuse type and rating specified for this product. Wear eye protection. Wear eye protection if exposure to high-intensity rays or laser radiation exists. WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 12 DANGER indicates an injury hazard immediately accessible as you read the marking. WARNING indicates an injury hazard not immediately accessible as you read the marking. CAUTION indicates a hazard to property including the product. The following symbol(s) may appear on the product: WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 13: Service Safety Summary

    Use Care When Servicing With Power On. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components. To avoid electric shock, do not touch exposed connections. WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 14 Service Safety Summary viii WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 15: Preface

    WVR8200 and WVR8300 Waveform Rasterizers. Where information is model-specific to either the WVR8200 or WVR8300 model, it is indicated as such. (See page 1-1, Configurations.) Related Manuals This manual assumes you have access to the following manuals when servicing this product.
  • Page 16 Procedure for checking performance and Product Documentation CD Rasterizers Specifications and list of specifications www.tektronix.com/manuals Performance Verification WVR and WFM Series Master Information Programmers command reference for Product Documentation CD Base (MIB) controlling the waveform rasterizer www.tektronix.com/manuals WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 17: Introduction

    Introduction...

  • Page 19: Service Strategy

    The performance verification procedures for this product are found in the WVR8200 and WVR8300 Waveform Rasterizers Specifications and Performance Verification Technical Reference located on the Product Documentation CD that ships with the product and is published on the Tektronix Web site. (See page ix, Related Manuals.) Options and Accessories...

  • Page 20: Hardware Installation

    Product Upgrade Hardware and software upgrades are available for all products, either as a field upgrade kit or as a free software download from the Tektronix Web site. The WVR8200 and WVR8300 Waveform Rasterizers User Manual includes instructions for updating product firmware.

  • Page 21: Theory Of Operation

    Theory of Operation...
  • Page 23 Theory of Operation The WVR8200 and WVR8300 are modular waveform rasterizers. They can be configured, with options, to accept Analog Composite inputs. Audio options can add inputs for digital only or analog audio capability. All models use an external DVI-I monitor for the display. All models also have outputs to drive serial digital and analog picture monitors.

  • Page 24: Figure 2-1: Main Block Diagram

    Theory of Operation Power Distribution is not shown in the block diagram but is covered at the end of this section. Figure 2-1: Main block diagram 2–2 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 25: Main Board

    It draws the audio bars, communicates with the front panel, and controls most other internal devices though either the SPI or the I C bus. Audio data is input to the control processor via the 8 bit HPI bus. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 2–3...

  • Page 26: Front Panel

    Both audio versions have the same basic processing engine. This uses an FPGA to route the audio input into two DSP chips, whose main function is to calculate the peak values for the selected meter ballistics (response characteristics). 2–4 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 27: Option Eye/Phy

    Options EYE and PHY provide the following features: Eye pattern display Equalized Eye pattern display Jitter readout Jitter Meter Cable Loss readout Test Signal Output Approx Cable readout Source Level readout Jitter waveform display Eye Amplitude readout WVR8200 and WVR8300 Waveform Rasterizers Service Manual 2–5...
  • Page 28 These measurements are read by the CPU on the Main board, which calculates Cable Loss, Approximate Cable Length, and Source Level for display in the SDI Status screen. 2–6 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 29: Figure 2-2: Option Eye/Phy Block Diagram

    Theory of Operation Figure 2-2: Option EYE/PHY block diagram WVR8200 and WVR8300 Waveform Rasterizers Service Manual 2–7...

  • Page 30: Fan Control

    Fuses on the Primary supply 5 V output protect the main board. The secondary supplies and their tolerances are specified in the troubleshooting section. The location of the supply test points is shown in the Maintenance section. 2–8 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 31: Adjustment Procedures

    Adjustment Procedures...

  • Page 33: Adjustments

    Verification procedure. For more details refer to Specifications and Performance Verification. Procedures NOTE. If you do not see the calibration case you are looking for, make sure to go to the next page using the up or down arrow key. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 3–1...
  • Page 34 2. Press the CONFIG button, and then select Utilities > Calibration. Press SEL to enter the calibration menu. 3. Use the up and down arrow buttons to navigate to the appropriate Eye Gain Adjust selection, and press SEL to start the calibration. 3–2 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 35 2. Connect an XGA to 5x BNC adapter cable to the PixMon output. 3. Connect the Y/Green video signal to the oscilloscope input. (Use an oscilloscope with a 75 Ω input, or a 75 Ω feed through termination.) WVR8200 and WVR8300 Waveform Rasterizers Service Manual 3–3...
  • Page 36 9. Use the General knob to adjust the signal zero level to 0 V on the oscilloscope. 10. Follow the instructions at the bottom of the calibration screen to Save and Exit Calibration mode. 3–4 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 37 6. Follow the on-screen instructions to adjust the response. 7. Follow the instructions at the bottom of the screen to Save and Exit calibration mode. 8. Repeat the Composite Analog Frequency Response test in the Performance Verification procedure. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 3–5...
  • Page 38 7. Check for an indication of 18 dBu in the newly adjusted audio bar. 8. If multiple inputs require adjustment, repeat this procedure for each input. 9. After all adjustments are made, you should perform a complete performance verification procedure. 3–6 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 39: Maintenance

    Maintenance...

  • Page 41: General Maintenance

    4. Nothing capable of generating or holding a static charge should be allowed on the work station surface. 5. Handle circuit boards by the edges when possible. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–1...

  • Page 42: Inspection And Cleaning

    Use only deionized water when cleaning the front-panel buttons. Use a 75% isopropyl alcohol solution as a cleaner and rinse with deionized water. Before using any other type of cleaner, consult your Tektronix Service Center or representative. 4–2 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 43: Table 4-1: External Inspection Check List

    Burned, broken, or cracked circuit-run plating. Resistors Burned, cracked, broken, Remove and replace blistered condition. damaged circuit board. Solder connections Cold solder or rosin joints. Resolder joint and clean with isopropyl alcohol. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–3...

  • Page 44: Troubleshooting

    General Safety Summary and Service Safety Summary found at the beginning of this manual. To prevent possible injury to service personnel or damage to electrical component, refer on how to prevent ESD. (See page 4-1.). 4–4 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 45 Unknown Problem section in the Symptoms and Causes table. The WVR8200 and WVR8300 Waveform Rasterizers are highly configurable and behavior is sometimes complex. Before troubleshooting in-depth, verify that: The installed options are as expected.

  • Page 46: Table 4-3: Required Test Equipment

    No LEDs lit and XGA output not working Perform general checks Perform primary power supply checks Perform secondary power supply checks Perform Front Panel button Troubleshooting Replace main circuit board or Front Panel assembly as indicated by above tests 4–6 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 47 Perform secondary power supply checks Eye Board Cable Version Run Advanced Diagnostics and look for other information Replace the EYE/PHY board Eye Register Readback Eye Board Power Supply Eye Board Cal EEPROM WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–7...
  • Page 48 DSY SDRAM Buffer 2 Memory Diagnostic Log Message: Search for an intermittent problem in the audio board, cables, or main board. Fail AUDIO_DSP_HEARTBEAT No text or traces on display Replace Main board 4–8 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 49 If the performance changes with the audio board removed, then you should perform the primary and secondary power supply checks and look for an excess load on one of the supplies. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–9...

  • Page 50: Detailed Troubleshooting Procedures

    If a fan is not spinning, measure the voltage on pin 1 of the connector on that fan. If the voltage is near 13 V, then replace the fan. If the voltage is not above 10 V, then replace the main board. 4–10 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 51 If that does not correct the problem, there may be a main board failure in the power switch circuit. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–11...

  • Page 52: Table 4-5: Main Board Secondary Supplies

    + 2.5 V 1.4 to 1.6 + 1.5 V 0.95 to 1.05 + 1.0 V 4.75 to 5.25 + 5 VA -4.75 to -5.25 – 5 VA 1.2 to 1.4 + 1.2 V 4–12 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 53: Table 4-6: Audio Board Secondary Supplies

    1. Connect an external XGA monitor to the DVI Primary output on the rear of the instrument. 2. Cycle the power and watch the external monitor. If the monitor does not display the boot up messages and normal operational screen, replace the main board. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–13...
  • Page 54 If the signal does transition, check pin 33 of J200 on the audio board. If the signal does not toggle on pin 33, replace the cable. 4–14 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 55 J26. If the signal on pin 25 does not toggle on the main board, then replace the cable; otherwise, replace the main board. If all of these steps pass, replace the audio board. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–15...
  • Page 56 To run the Advanced diagnostics, press the CONFIG button, then select Utilities > Run Advanced Diags. Advanced Diagnostics includes tests that check interfaces between FPGAs and memory on the Main board. If any of these tests fails, replace the Main board. 4–16 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 57 Pin 63 is the data line and the signal will have a somewhat random look depending on the audio source. Verify that the signal is toggling and is ≈3 V e. If either signal is bad, suspect the cable; otherwise replace the main board. WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–17...
  • Page 58 Operation is unlikely to fail if the basic Eye pattern display works correctly. It is normal for these measurements to stop or become intermittent if there is excessive waveform noise, aberrations, jitter, or cable loss. 4–18 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 59: Figure 4-1: Main Board Indicator Led, Connector, And Test Point Locations

    General Maintenance Figure 4-1: Main board indicator LED, connector, and test point locations WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–19...

  • Page 60: Figure 4-2: Options Ad And Dpe Audio Board, Component Side

    General Maintenance Figure 4-2: Options AD and DPE Audio board, component side 4–20 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 61: Figure 4-3: Options Ad And Dpe Audio Board Back Side Indicator Led And Test Point Locations

    General Maintenance Figure 4-3: Options AD and DPE Audio board back side indicator LED and test point locations WVR8200 and WVR8300 Waveform Rasterizers Service Manual 4–21...

  • Page 62: Repackaging Instructions

    Type and serial number of the instrument. Reason for returning. A complete description of the service required. Mark the address of the Tektronix Service Center and the return address on the shipping carton in two prominent locations. 4–22 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 63: Replaceable Parts

    Replaceable Parts...

  • Page 65: Parts Ordering Information

    For more information about the module exchange program, call 1-800-833-9200. Outside North America, contact a Tektronix sales office or distributor; see the Tektronix Web site for a list of offices: www.tektronix.com. Module Repair and Return. You may ship your module to us for repair, after which we will return it to you.

  • Page 66: Using The Replaceable Parts Lists

    Orderable modules show the figure number without an index number. Tektronix part number Use this part number when ordering replacement parts from Tektronix. 3 and 4 Serial number Column three indicates the serial number at which the part was first effective.
  • Page 67 211-0734-00 SCREW,MACHINE; 6-32 X 0.25O,FLH100,STL,CDPL,T-10 TORX DR 200-4873-00 COVER; TOP,STANDARD INSTRUMENT,0.050 AL,SAFETY CONTROLLED 441-2576-00 CHASSIS, MAIN; 0.050 AL, SAFETY CONTROLLED, WVR8200, WVR8300 343-0003-00 CLAMP, LOOP; 0.25 ID, PLASTIC 210-0457-00 NUT, PL, ASSEM WA; 6-32 X 0.312, W/LOCKWASHER, STEEL, ZINC FINISH 174-5848-00 CA ASSY, SP;...
  • Page 68 OUTPUT, WITH CONN & HOUSING, SAFETY CONTROLLED 211-1161-00 SCREW,MACHINE; 4-40 X 1.500,PAN HEAD,T-10 TORX,ZINC PL 407-5375-00 BRACKET; FAN MOUNTING, 0.050 AL, SAFETY CONTROLLED 210-0457-00 NUT, PL, ASSEM WA; 6-32 X 0.312, W/LOCKWASHER, STEEL, ZINC FINISH 5–4 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 69: Figure 5-1: Replaceable Parts (Standard)

    Replaceable Parts Figure 5-1: Replaceable parts (standard) WVR8200 and WVR8300 Waveform Rasterizers Service Manual 5–5...
  • Page 70 CABLE ASSEMBLY; POWER SUPPLY, 10 PIN, SAFETY CONTROLLED 174-5683-00 CABLE ASSEMBLY, CAT5E, MALE TO MALE, ETHERNET 174-5653-00 CABLE ASSEMBLY; POWER SUPPLY, HIGH CURRENT; SAFETY CONTROLLED 174-5682-00 CABLE ASSEMBLY, FRONT PANEL, 10 PIN Quantity varies with instrument options. 5–6 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 71: Figure 5-2: Replaceable Parts (Standard)

    Replaceable Parts Figure 5-2: Replaceable parts (standard) WVR8200 and WVR8300 Waveform Rasterizers Service Manual 5–7...
  • Page 72 WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH 220-0497-00 NUT, PLAIN, HEX; .5-28 X .562 HEX, BRS, NI (NICKEL) PLATED 211-0722-00 SCREW, MACHINE; 6-32 X 0.250, PNH, STEEL, ZINC FINISH, T-15 TORX DR 5–8 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 73: Figure 5-3: Replaceable Parts (Options)

    Replaceable Parts Figure 5-3: Replaceable parts (options) WVR8200 and WVR8300 Waveform Rasterizers Service Manual 5–9...
  • Page 74 ADAPTER, CONN; VGA FEMALE TO DVI MALE DISPLAY See Description CABLE ASSY, POWER: OPTION COUNTRY N. AMERICA 161-0216-00 UNIV EURO 161-0215-00 161-0066-10 161-0066-13 AUSTRALIA SWITZERLAND 161-0154-00 JAPAN 161-A008-00 CHINA 161-0304-00 INDIA 161-0400-00 5–10 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...
  • Page 75 MANUAL, TECH; ND-NC; TEKTRONIX SUPPLEMENTAL INFORMATION SHEET FOR THE PEOPLES REPUBLIC OF CHINA; CHINA ROHS 012-1721-00 CABLE ASSY;25 FT.,W/CONNECTOR,D-SUB,9 PIN MALE Optional Accessories 012-1720-00 CABLE ASSY;100 FT., W/CONNECTOR, D-SUB, 9 PIN MALE WVR8200 and WVR8300 Waveform Rasterizers Service Manual 5–11...
  • Page 76 CABLE ASSY, PWR; 3, 1.0MM SQ, 250V/10A, 2.5 METER, STR, IEC320, 3C CERTIFICATION, RCPT, CHINA, SAFETY CONTROLLED 161-0400-00 Option A11 India CABLE ASSY, PWR; 3, 1.0MM SQ, 250V/6A, 2.5 METER, STR, IEC320/C13, RCPT, PLUG, INDIA 5–12 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

  • Page 77: Figure 5-4: Replaceable Parts (Wvr8Rfp Remote Front Panel)

    Replaceable Parts Figure 5-4: Replaceable parts (WVR8RFP Remote Front Panel) WVR8200 and WVR8300 Waveform Rasterizers Service Manual 5–13...

  • Page 78: Figure 5-5: Analog Audio Breakout Cable Assembly

    Analog Audio Breakout Cable Optional Accessory 012-1688-00 CABLE ASSEMBLY; ANALOG/AUDIO BREAKOUT 200-4804-00 COVER; SHIELD,ELEC CONN,37 POS DSUB,ZINC 131-0422-00 CONN,DSUB; SLDR CUP/PNL,;MALE,STR,37 POS,0.112 CTR,0.186 H X 0.126 TAIL,0.125 DIA THRU MTG Figure 5-5: Analog audio breakout cable assembly 5–14 WVR8200 and WVR8300 Waveform Rasterizers Service Manual...

This manual is also suitable for:
