WVR8200 and WVR8300 User Manual
The following elements are visible on page 2 of the UHDTV1/4K video session
display:
Statistics: The statistics table displays the status and statistical values for
the following errors:
RGB Gamut Error: Evaluates the SDI input signal against the thresholds
set for the Diamond display in the CONFIG > Gamut Thresholds
submenu. If an error occurs, Error is displayed for one second after a
violation is detected.
Cmpst Gamut Error: Evaluates the SDI input signal against the
thresholds set for the Arrowhead display in the CONFIG > Gamut
Thresholds submenu. If an error occurs, Error is displayed for one second
after a violation is detected.
Luma Gamut Error: Evaluates the SDI input signal against the
thresholds set for Luma in the CONFIG > Gamut Thresholds submenu.
If an error occurs, Error is displayed for one second after a violation is
detected.
Y Chan CRC Error: Indicates that the Y Channel embedded CRC
value does not match the calculated CRC value, which indicates that a
transmission error has occurred.
C Chan CRC Error: Indicates that the C Channel embedded CRC
value does not match the calculated CRC value, which indicates that a
transmission error has occurred.
Y Anc Checksum Error: Indicates that the Y channel ancillary embedded
checksum value does not match the calculated checksum value, which
indicates that a transmission error has occurred.
C Anc Checksum Error: Indicates that the C channel ancillary embedded
checksum value does not match the calculated checksum value, which
indicates that a transmission error has occurred.
Status: Displays the status of the associated error. Status can be:
OK – Indicates that no error has occurred within the last second or that the
embedded CRC value matches the calculated CRC value.
Invalid – Indicates the CRC value is corrupted.
Missing – Indicates that the EDH packet is missing, which probably
means that the EDH packet was not inserted by the source.
Error – Indicates that an error has occurred within the last second or
that the embedded CRC value does not match the calculated CRC value,
which indicates that a transmission error has occurred. The Error indicator
is displayed for one second after an error occurs.
