Monitoring the SDI physical layer
To configure physical layer alarms
122
10. Use the General knob to increase or decrease the cable length setting. The
maximum length you can enter is 300 meters; the minimum length is 0 meters.
11. Select Eye Amplitude Max. Use the General knob to increase or decrease
the setting. The maximum amplitude you can enter is 1010 mV; the minimum
amplitude is 700 mV.
12. Select Eye Amplitude Min. Use the General knob to increase or decrease the
setting. The maximum amplitude you can enter is 10 mV below the current
Eye Amplitude Max setting; the minimum amplitude is 530 mV.
13. Select Eye Risetime Max. Use the General knob to increase or decrease the
setting. The rise time range for SD is 410 ps to 3000 ps. The rise time range
for HD and 3G is 10 ps to 1000 ps.
14. Select Eye Risetime Min. Use the General knob to increase or decrease the
setting.
15. Select Eye Falltime Max. Use the General knob to increase or decrease the
setting. The fall time range for SD is 410 ps to 3000 ps. The fall time range
for HD and 3G is 10 ps to 1000 ps.
16. Select Eye Falltime Min. Use the General knob to increase or decrease the
setting.
17. Select Eye Rise-Fall Delta. Use the General knob to increase or decrease the
setting. The maximum value you can enter is 1000 ps; the minimum value
is 0 ps.
NOTE.
You can read more about alarms in the Configuring Alarms section.
1. From the CONFIG menu, select Alarms > Physical Layer.
2. Press the SEL button.
3. Use the arrow keys and the SEL button to mark the squares for the alarms
you want to monitor.
WVR8200 and WVR8300 User Manual
