Closed caption (CC), Teletext, AFD, and Safe Area compliance
To display CC
Usage notes
182
1. Select a tile.
2. Press and hold the PICT button to display the Picture pop-up menu.
3. Select CC/Teletext Format and select the CC type, if any, you want to
display.
4. Select the channel, service, or page to display.
The Picture display includes Closed Captioning in the area designated by the
Closed Caption data. (See Figure 89.)
5. Press the PICT button again to dismiss the Picture pop-up menu.

Figure 89: Closed caption display area

PICT displays in individual tiles allow their Services and Pages to be selected
independently.
CC text is not captured with the Picture image when using Freeze.
CC/Teletext setups are also stored when saved with Presets and restored at
power on.
The CC alarms are available from the Configuration menu in the Alarms
submenu under Closed Captions/Metadata.
Teletext can be viewed as captions or as a whole page.
