Monitoring audio
176
Table 6: Channel Mode versus Listening Modes (cont.)
Channel mode Listening mode
2/2 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
3/1 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
2/1 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
3/0 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
Main channel output function
All 2/2 channels + EX decode of back surround
All 2/2 channels
Default to Stereo mode
Default to Full mode
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
Default to Full mode
All 3/1 channels
S mixed into L and R with smix coefficient
C mixed into L and R with cmix coefficient
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
Default to Full mode
All 2/1 channels
S mixed into L and R with smix coefficient
Default to Full mode
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
Default to 3 Stereo mode
Default to 3 Stereo mode
All 3/0 channels
C mixed into L and R with cmix coefficient
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
