A 2/0 encoded Dolby stream is assumed to be Pro Logic encoded already and is
Pro Logic decoded to produce a LCRS output. Again, the surround channel is
reduced 3 dB and reproduced in both the Ls and Rs bars.
Any PCM input is decoded the same as a 2/0 Dolby Digital input.
Pro Logic 3 Stereo. Pro Logic 3 Stereo creates a Lt/Rt downmix of any input with
three or more channels. This Lt/Rt downmix will then use Pro Logic decoding
to produce a center channel and provide LCR bars.
A 2/0 encoded Dolby stream is assumed to be Pro Logic encoded already and is
Pro Logic decoded to produce a LCR output.
Any PCM input is decoded to provide LCRS channels where the surround channel
is reduced 3 dB and reproduced in both the Ls and Rs bars.
Pro Logic Phantom. Pro Logic Phantom creates a Lt/Rt downmix of any input
with three or more channels. This Lt/Rt downmix will then use Pro Logic
decoding to produce a surround channel and provide LCS surround channels. This
surround channel is reduced 3 dB and reproduced in both the Ls and Rs bars.
A 2/0 encoded Dolby stream is assumed to be Pro Logic encoded already and is
Pro Logic decoded to produce a LRS output. Again, the surround channel is
reduced 3 dB and reproduced in both the Ls and Rs bars.
Any PCM input is decoded to provide LCRS channels where the surround channel
is reduced 3 dB and reproduced in both the Ls and Rs bars.

Table 6: Channel Mode versus Listening Modes

Channel mode Listening mode
3/2 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
Main channel output function
All 3/2 channels + EX decode of back surround
All 3/2 channels
3 Stereo downmix of 3/2 channels
Phantom downmix of 3/2 channels
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
Monitoring audio
