Configuring signal inputs
To customize input labels
30
You may select up to eight channels of video from 2xHD video sources, but only
the first four are displayed in Multi-Input mode. 2xHD video formats may be used
for 3D video content in which the left eye view is typically carried in channel 1
and the right eye in channel 2. The 2xHD formats are defined by SMPTE 425
as an option for 3 Gb/s Level B SDI video. 2xHD formats are available in 720p,
1080i, and 1080p (23.98 - 30 fps).

Figure 17: Waveform display in Multi-Input mode showing multiple channels

You can name the input labels from the CONFIG > Graticules and Readouts
> Input Labels menu. Once you are in the Input Labels menu, select an input
and then press the SEL button. A dialog box will appear allowing you to name
the input.
WVR8200 and WVR8300 User Manual
