WVR8200 and WVR8300 User Manual
Short Pd: The Short Period defines the duration of the short Loudness average
and is defined by the user within the Config menu for Loudness Settings.
Chans: The Channels Summations shows the number of channels that are
currently summed together for the Loudness average.
Changed Since Last Reset: Either Yes or No. Indicates whether an error has
occurred since the last reset.
Audio Session pop-up menu.
NOTE.
To reset, stop, or start an individual audio or video session, select the
tile in which it is displayed and use the SEL button, right arrow key, and left
arrow key, respectively. Remember that the STATUS pop-up menu must be closed;
otherwise, the button and key presses will navigate through that menu.
Mute Alarms: Mutes alarms for all Status display types.
Loudness Avg: Allows you to choose the duration over which the loudness
count is averaged: Long is calculated on the interval of time since the last
session reset; Short is calculated on the most recent 10 second interval.
All Sessions Reset: Globally resets any and all audio sessions displayed in all
panes, regardless of the display and session from which it is executed.
All Sessions Start: Globally starts any and all stopped audio sessions
displayed in all panes, regardless of the display and session from which it
is executed.
All Sessions Stop: Globally stops any and all stopped audio sessions
displayed in all panes, regardless of the display and session from which it
is executed.
Display information
83
