CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
If the selected location contains valid data, the following screen will be displayed:
New Config has been
Loaded from Loc 9 (ENT)
Pressing ENTER or CLEAR will take the user back to the previous menu.
6.18

UTILITY

UTIL: Buffer Clock Ref
ID 1:1 VFD Firmware FAST
Select Buffer, Clock, Ref, ID, 1:1, VFD, Firmware or FAST using the
◄ ►
According to the selection, the following sub-menus are displayed:
6.18.1

(UTIL) BUFFER (Buffer re-center)

Press ENTER to Re-Center
the Receive Buffer
Pressing ENTER will cause a forced re-centering of the Plesiochronous/Doppler buffer.
6.18.2

(UTIL) CLOCK (Set real-time clock)

Edit Real-Time Clock:
12:00:00 24/04/03(◄ ►,▲ ▼)
Edit the time and date settings of the real-time clock. This is accomplished by selecting
the digit to be edited, using the
using the
with international convention, the date is shown in DAY-MONTH-YEAR format.
IMPORTANT
arrow keys, then press ENTER.
arrow keys. The user should then press ENTER. Note that in accordance
▲ ▼
◄ ►
arrow keys. The value of the digit is then changed
6–56
Revision 3
MN/CDM570L.IOM
