Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Equipment ID N/A 11 bytes
Rx Buffer Size RBS= 1 byte, value
of 0 thru 9
6
Description of Arguments
to Query
Query only.
Unit returns information concerning the equipment identification,
and the option field, in the form abbbcdefghi;
where:
a = Turbo option: 0 = None, 1 = Turbo, 2 = TPC/LDPC
bbb = defines the modem model number
CDM-570 = 570
CDM-570L = 571
c = RS Codec Option: 0 = None, 1 = Installed
d = Data Rate Option: 0 = Base (512 kbps), 1 = up to 2048 kbps,
2 = up to 5000 kbps, 3 = up to 5000 kbps,
e = Higher-order modulation: 0= None, 1 = 8-PSK/8-QAM,
2 = 16QAM, 3 = 8-PSK/8-QAM and 16QAM
f = IP Module: 0 = None, 1 = Installed
g = BUC option: 0 = None, 1 = 100 Watt, 2 = 150 Watt
h = Spare – for future use
i = Spare – for future use
Example: EID=157101311xx means Turbo, CDM-570L, No RS
codec, up to 2048bps, 8-PSK/8-QAM and 16-QAM, IP Module
installed, 100 Watt BUC supply installed
Command or Query.
Rx buffer size, where:
0 = Buffer disabled (Clock mode = Rx satellite)
1 = +/- 1024 bits
2 = +/- 2048 bits
3 = +/- 4096 bits
4 = +/- 8192 bits
5 = +/- 16384 bits
6 = +/- 32768 bits
7= +/- 128 bits
8 = +/- 256 bits
9 = +/- 512 bits
Example: RBS=0
Update for Remote Commands and Front
Panel Ethernet Menus
Query
Response to (Instruction
Command Code and
Qualifier)
N/A EID?
RBS= RBS?
RBS?
RBS*
RBS#
Response to Query
EID= abbbcdefghi
(see description of
arguments)
570 is the CDM-570
571 is the CDM-570L
RBS=x
(same format as
command argument)
