CDM-570/570L Satellite Modem with Optional IP Module
SNMP Interface
19.6.7.4 WAN Statistics
The cdmipWanFpgaStatistics section collects statistics reported on the WAN (satellite
interface) FPGA.
19.6.7.5 Compression Statistics
This subgroup contains the Compression statistics elements. This is implemented as a
table with maximum number of configured QoS rules, as the rows.
Note: This subgroup will only be accessible in the MIB tree if the Header and/or
19.6.8

QoS Rules Group

The cdmipQosRules group allows the user to configure the QoS feature. The group
contains the QoS table which allows the user to add rules to define how different types of
traffic will be treated by the router.
19.7

CDM-570/570L Private MIB

Whenever modifying the Modulator or Demodulator parameters by SNMP, the user must
be aware that the following variables must be executed in this order:
IMPORTANT
1. FEC (Forward Error Correction)
2. Modulation or Demodulation
3. Code Rate
4. Data Rate
For detailed OID information please refer to the actual MIB file.
19.7.1

System Group

This group contains basic system information concerning the modem, including serial
number, temperature, and configured modem options.
Compression FAST feature has been purchased and activated. Otherwise, both
gets GETs and sets SETs on these OIDs will return errors.
