CDM-570 Satellite Modem with Optional IP Module
The user is prompted from 1 of 4 sub-menu branches using the
press ENT.
F.2.3.9 (ODU,ENABLE,1:1,CSAT#1)
(ODU,ENABLE,1:1,CSAT#2)
(ODU,ENABLE,STAND-ALONE)
ODU CONFIG: Transmitter
Receiver
The user uses this menu item to select either the 'Transmitter configuration branch",
"Receiver configuration branch" or "Miscellaneous configuration branch". Use the
arrow keys, then press ENT.
F.2.3.10 (ODU,ENABLE,1:1,CSAT#1,CONFIG)
(ODU,ENABLE,1:1,CSAT#2,CONFIG)
(ODU,ENABLE,STAND-ALONE,CONFIG)
ODU TX: Frequency Atten
Amplifier Mute Slope
This menu item is used to select which ODU Transmitter parameter is to be modified.
Use the
F.2.3.11 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER)
FREQUENCY
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER)
FREQUENCY
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER)
FREQUENCY
ODU Tx Frequency:
5912.5 MHz (
The user is prompted to edit the transmit frequency. This is accomplished by selecting
the digit to be edited, using the
using the
◄ ►
Misc (
◄ ► arrow keys, then press ENT.
◄ ►,▲ ▼,
▲ ▼
arrow keys. The user may then press ENT.
Addendum B- 5
CONFIG (Configuration)
CONFIG (Configuration)
CONFIG (Configuration)
,ENT)
◄ ►
ENT)
◄ ► arrow keys. The value of the digit is then changed
ODU Operation
◄ ►
arrow keys, then
◄ ►
TRANSMITTER
TRANSMITTER
TRANSMITTER
