Comtech EF Data CDM-570 Installation And Operation Manual page 211

CDM-570/570L Satellite Modem with Optional IP Module
IP Module Ethernet Interface Overview
The following table can be used as a reference for some well known Port numbers:
Port Description
1 TCP Port Service Multiplexer (TCPMUX)
7 ECHO
20 FTP - Data
21 FTP - Control
22 SSH Remote Login Protocol
23 Telnet
25 Simple Mail Transfer Protocol (SMTP)
42 Host Name Server (Nameserv)
53 Domain Name System (DNS)
69 Trivial File Transfer Protocol (TFTP)
70 Gopher Services
80 HTTP
108 SNA Gateway Access Server
109 POP2
110 POP3
115 Simple File Transfer Protocol (SFTP)
IMPORTANT
15.4.4.2 Minimum/Maximum Bandwidth QoS Mode
QoS Rules can be assigned to up to 32 different types of flows to be defined by the user.
Flows can be defined by any combination of Protocol (FTP, UDP, RTP, etc.),
Source/Destination IP (specific or range), and/or Layer 3 Source/Destination Port.
Weighted Random Early Detection (WRED) – The Min/Max BW QoS mode allows
the user to select Weighted Random Early Detection (WRED). Without WRED, output
buffers fill during periods of congestion. When the buffers are full, tail drop occurs; all
additional packets are dropped. Since the packets are dropped all at once, global
synchronization of TCP hosts can occur as multiple TCP hosts reduce their transmission
rates. As the congestion clears, the TCP hosts increase their transmission rates, resulting
in waves of congestion followed by periods where the transmission link is not fully used.
Port
118
119
137
139
150
156
161
179
190
197
396
443
444
546
547
1080
Once the QoS Rules are defined, each type of traffic flow
should be isolated and sent to verify that it is being sent in
the intended QoS Rule.
15–11
Description
SQL Services
Newsgroup (NNTP)
NetBIOS Name Service
NetBIOS Datagram Service
NetBIOS Session Service
SQL Server
SNMP
Border Gateway Protocol (BGP)
Gateway Access Control Protocol (GACP)
Directory Location Service (DLS)
Novell Netware over IP
HTTPS
Simple Network Paging Protocol (SNPP)
DHCP Client
DHCP Server
Socks
Revision 3
MN/CDM570L.IOM
