CDM-570/570L Satellite Modem with Optional IP Module
Serial Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Initialize IEP= None
Events Pointer
Statistics SSI= 1 byte,
Sample numerical
Interval
Number of N/A 3 bytes
Unread stored
Statistics
Retrieve next 5 N/A 130 bytes
unread Stored
Statistics
Clear All CAS= None
Stored
Statistics
Description of Arguments
to Query
Command only.
Resets internal pointer to allow RNE? queries to start at the
beginning of the stored events log.
Command or Query.
Used to set the sample interval for the Statistics Logging Function
SSI=x, where x= 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging
function.
Example: SSI=3 means 30 minutes
Query only.
Unit returns the number of stored Statistics, which remain Unread,
in the form xxx.
Note: This means unread over the remote control.
Example: NUS=247
Query only.
Unit returns the oldest 5 Stored Statistics, which have not yet been
read over the remote control. Reply format:
{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body, where Sub-body=
AA.ABB.BC.CD.Dddmmyyhhmmss,
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyyhhmmss = date/time stamp.
If there are no new events, the unit replies with RNS*. If there are
less than 5 statistics to be retrieved, the remaining positions are
padded with zeros.
Command only.
Forces the software to clear the software statistics log.
Example: CAS=
Note: This command takes no arguments.
Response to
Command
IEP=
IEP#
SSI=
SSI?
SSI*
SSI#
N/A
N/A
CAS=
CAS?
CAS*
CAS#
13–20
Revision 3
MN/CDM570L.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
N/A N/A
SSI? SSI=x
(see description for
details of argument)
NUS? NUS=xxx
(see description of
arguments)
RNS? RNS={CR}AA.ABB.B
C.CD.Dddmmyyhhmms
s{CR}AA.ABB.BC.CD.
Dddmmyyhhmmss{
CR}AA.ABB.BC.CD.D
ddmmyyhhmmss{CR}A
A.ABB.BC.CD.Dddmm
yyhhmmss{CR}AA.AB
B.BC.CD.Dddmmyyhh
mmss
(see description for
details of arguments)
N/A N/A
