Config Group - Comtech EF Data CDM-570 Installation And Operation Manual

CDM-570/570L Satellite Modem with Optional IP Module
SNMP Interface
19.7.2

Config Group

This group allows the user to configure the modem's transmitter, receiver, framing
options (AUPC and EDMAC), data interfaces, reference, and alarm masks. In addition,
LNB and BUC units attached to the modem can also be configured.
19.7.2.1 Remote Control Parameters
The cdm570LRemoteControl section allows the user to configure the management IP
address and subnet mask for the modem. The user can also verify that the modem is in
"Remote" state for management through SNMP.
19.7.2.2 Tx Parameters
The cdm570LTx section allows the user to configure the modem's modulator.
19.7.2.3 Rx Parameters
The cdm570LRx section allows the user to configure the modem's demodulator.
19.7.2.4 Frame Parameters
The cdm570LFrame section allows the user to turn framing on and off. When framing is
enabled, the user can also configure Embedded Distant-End Monitor and Control
(EDMAC) parameters and Automatic Uplink Power Control (AUPC) parameters.
19.7.2.5 Interface Parameters
This section allows the user to configure the modem's data interface.
19.7.2.6 Reference Parameters
The sections allows the user to configure the modem's reference clock.
19.7.2.7 Alarm Mask Parameters
This section allows the user to mask alarms that the user does not want to see.
