Comtech EF Data CDM-570 Installation And Operation Manual page 309

CDM-570/570L Satellite Modem with Optional IP Module
SNMP Interface
OID
IfOutErrors
IfOutQLen
IfSpecific
19.5.2.2 AT Group
This group contains a table that permits mappings from network addresses (i.e., IP
addresses) to physical addresses (i.e., MAC addresses). This group is depreciated.
19.5.2.3 The Address Translation table
This table is implemented per RFC1213.
19.5.2.4 IP Group
This group is implemented per RFC1213.
19.5.2.5 The IP Address Table
This table is implemented per RFC1213.
19.5.2.6 The Route Table
Because the CDM-570/570L does not use a standard route table, the functionality
usually provided by the ipRouteTable is implemented in the IP-Controller's private MIB.
Please use the IP Controller private MIB's route table to add, change, or delete routes.
19.5.2.7 The Net to Media Translation table
This table is implemented per RFC1213.
19.5.2.8 Additional IP Objects
The ipRoutingDiscards OID is the number of routing entries which were chosen to be
discarded even though they are valid.
Per RFC1213
Per RFC1213
This OID is not used.
19–7
MN/CDM570L.IOM
Description
Revision 3
