CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.14.3

(MONIT) EVENT-LOG (STORED EVENTS)

If the user selects Stored Events, the following sub-menu is displayed:
Stored Events:
Clear-All
Select View or Clear-All, using the
IMPORTANT
(◄ ►,ENTER)
(MON, EVENTS) VIEW
If the user selects View, the following screen is displayed:
Log23: 30/11/02 10:37:32
Fault - Demod Lock (▲ ▼)
The user may scroll backwards or forwards through the entries in the event log,
using the arrow keys. Pressing ENTER or CLEAR will take the user back
▲ ▼
to the previous menu. The event log can store up to 255 events. When a fault
condition occurs, it is time-stamped and put into the log. Similarly, when the
fault condition clears, this is also recorded, as shown below:
Log240:30/11/97 10:37:35
Clear - Demod Lock (▲ ▼)
If the user selects Clear-All, the following screen is displayed:
Clear all Stored Events?
(▲ ▼, ENTER)
No Yes
If the user selects Yes, the event log is cleared, and the user is taken directly back
to the previous menu. However, if there are faults present on the unit at this time,
they will be re-time-stamped, and new log entries will be generated.
Note that in accordance with international convention, the
date is shown in DAY-MONTH-YEAR format.
View
◄ ►
arrow keys, then press ENTER.
6–43
Revision 3
MN/CDM570L.IOM
