Comtech EF Data CDM-570 Installation And Operation Manual page 368

CDM-570 Satellite Modem with Optional IP Module
F.2.3.12 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER)
ATTEN (Attenuation)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER)
ATTEN (Attenuation)
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) ATTEN
(Attenuation)
ODU Tx Attenuation:
15.00 dB
The user is prompted to edit the transmit attentuation. This is accomplished by selecting
the digit to be edited, using the
using the
F.2.3.13 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER)
AMPLIFIER
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER)
AMPLIFIER
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER)
AMPLIFIER
ODU Tx Amp State:
On
The user is prompted to select either On or Off, using the
ENT.
F.2.3.14 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER) MUTE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER) MUTE
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) MUTE
ODU Tx Mute State:
Muted
The user is prompted to select either Muted or Unmuted, using the
then to press ENT.
F.2.3.15 (ODU,ENABLE,1:1,CSAT#1,CONFIG,TRANSMITTER) SLOPE
(ODU,ENABLE,1:1,CSAT#2,CONFIG,TRANSMITTER) SLOPE
(ODU,ENABLE,STAND-ALONE,CONFIG,TRANSMITTER) SLOPE
ODU Tx Slope Mode:
Manual
◄ ►,▲ ▼,
(
◄ ►
▲ ▼ arrow keys. The user then presses ENT.
◄ ►
Off (
◄ ►
Unmuted (
Calibrated (
Addendum B- 6
ENT)
arrow keys. The value of the digit is then changed
,ENT)
,ENT)
◄ ►
)
ODU Operation
◄ ► arrow keys, then to press
◄ ► arrow keys,
