CDM-570 Satellite Modem with Optional IP Module
F.2.3.40 (ODU,ENABLE,1:1,CSAT#1)
(ODU,ENABLE,1:1,CSAT#2)
(ODU,ENABLE,STAND-ALONE)
ODU MONITOR: Tx Rx Misc
Pwr-Supp1 Pwr-Supp2 (◄ ►)
The operator uses this menu item to select enter 1 of 5 'Monitor Windows'. Use the ◄
► arrow keys, then press ENT.
F.2.3.41 (ODU,ENABLE,1:1,CSAT#1,MONITOR)
(ODU,ENABLE,1:1,CSAT#2,MONITOR)
(ODU,ENABLE,STAND-ALONE,MONITOR)TX (Transmitter)
TX: SynTune=04.8 Pwr=040
IFLO = 10.7
This window provides the Tx Synthesizer and IFLO tuning voltages, the RF Output
Power in dBm and the Transmitter temperature. Press ENT.
F.2.3.42 (ODU,ENABLE,1:1,CSAT#1,MONITOR)
(ODU,ENABLE,1:1,CSAT#2,MONITOR)
(ODU,ENABLE,STAND-ALONE,MONITOR)RX (Receiver)
RX: Synth Tune = 03.1
IFLO = 10.9
This window provides the Rx Synthesizer and IFLO tuning voltages and the Receiver
temperature. Press ENT.
F.2.3.43 (ODU,ENABLE,1:1,CSAT#1,MONITOR)
(ODU,ENABLE,1:1,CSAT#2,MONITOR)
(ODU,ENABLE,STAND-ALONE,MONITOR)MISC
MISC: Ref Tune = 03.0
LNA=000.0mA FAN=568.0mA
This window provides the Internal Reference Oscillator tuning voltages, the LNA Current
in milliamps and the Fan Current in milliamps. Press ENT.
o
C
Temp = 27
o
C
Temp = 28
Addendum B- 14
MONITOR
MONITOR
MONITOR
TX (Transmitter)
TX (Transmitter)
RX (Receiver)
RX (Receiver)
MISC
MISC
ODU Operation
