CDM-570/570L Satellite Modem with Optional IP Module
SNMP Interface
cdmipsupport@comtechefdata.com. In order for this to work, the user is required to enter
the IP address of their outgoing SMTP mail server and the domain name for that server.
19.6.1.6 SNMP Traps
This cdmipSnmp subsection controls where SNMP traps are sent and the community
string used in sending traps. Either V1 or V2 traps can be sent.
19.6.2

Interface Group

This group controls the parameters of the modem's Ethernet and satellite interfaces.
19.6.2.1 Ethernet Interface Subgroup
This subgroup defines the modem's Ethernet interface. These include parameters for
setting the Ethernet speed, IP address, and IP address subnet prefix length.
19.6.2.2 Satellite Interface Subgroup
This subgroup defines the modem's satellite interface.
CAUTION
19.6.3

Route Table Group

The cdmipIpRouteTable allows a user to define how the packets that the CDM-
570/570L receives are routed. By this table, a user can define which DES key to use for a
route.
Note: In order for the CDM-570/570L to properly pass packets over the satellite
interface, the user MUST provide the appropriate IP to HDLC address mapping in
the Route table. This Route table is Comtech EF Data's proprietary
implementation, where the user specifies a HDLC address as a next-hop for a
route destined to the satellite interface.
Changing the HDLC Address mode between Point-to-Point Mode, Small
Network Mode, and Large Network Mode forces the system to reboot.
System configuration will be saved before re-booting. Please make sure you
are setting the correct value.
19–11
Revision 3
MN/CDM570L.IOM
