6.5.2 (CONFIG, REMOTE) ETHERNET
If Ethernet is selected, the following sub menu is displayed:
Ethernet Config: Gateway
Address MAC SNMP
(CONFIG, REMOTE, ETHERNET) GATEWAY
If Gateway is selected, the following sub-menu is displayed:
Ethernet IP Gateway:
192.168.001.002
Edit the IP Gateway Address for the Ethernet M&C port for this unit.
This is accomplished by selecting the digit to be edited, using the ◄ ►
arrow keys. The value of the digit is then changed using the
keys. The user should then press ENTER.
(CONFIG, REMOTE, ETHERNET) ADDRESS
If Address is selected, the following sub-menu is displayed:
Ether IP Address/Range:
192.168.001.002/24 (◄ ►,▲ ▼)
Edit the IP Address and Range for the Ethernet M&C port for this unit.
This is accomplished by selecting the digit to be edited, using the ◄ ►
arrow keys. The value of the digit is then changed using the
keys. The user should then press ENTER.
(CONFIG, REMOTE, ETHERNET) MAC
If MAC is selected the following information-only sub-menu is
displayed:
Once the MAC address has been noted, the user should then press
ENTER or CLEAR.
M&C Port MAC Address:
00-06-B0-00-01-06
Update for Remote Commands and Front Panel
Ethernet Menus
(◄ ►)
(◄ ►,▲ ▼)
