CDM-570/570L Satellite Modem with Optional IP Module
IP Module CLI and Telnet Operation
17.2.8.4 Administrative Database Operations Page
Administrative Database Operations Page is activated from Operations and Maintenance
Page.
The Database Operations option allows the user to view, save, or erase an existing user
configuration of the IP Module. An IP Module uses these types of configuration files to
initialize itself on power-up.
The User Configuration File allows a User to over-write the values defined in the Factory
Configuration file. This allows full customization of a IP Module without erasing a set of
parameters defined from the factory. The User configuration file can also be retrieved or
overwritten via FTP by specifying the filename 'param1'.
The Administrative Database Operations Page contains the following options/fields:
Menu Options/Fields
Save Parameters to
permanent storage
Restore Factory Default
Load Parameters from
permanent storage
Save Parameters
Exit
Entry
P This option allows a user to save the current configuration of
IP M
the odule to permanent storage. This configuration will be
restored on each successive power cycle.
R IP M
Restores the
the factory.
F
This option overwrites the current configuration of the
M
odule with the configuration last saved to permanent storage.
It allows the user to perform an "Undo" type operation if the
M
odule is put into an undesirable state by the user.
S This option allows a user to save the current configuration of
IP M
the odule to permanent storage. This configuration will be
restored on each successive power cycle.
X This option allows a user to exit the current menu and return to
its parent menu.
17–67
MN/CDM570L.IOM
Description
odule settings to "safe" values as defined by
Revision 3
IP
IP
