D.3.3 The HDLC MAC address is user configurable.

D.3.4 Setting IP Address(es)
Step
1 From the Main Menu select Network Interface Configuration sub-menu [I].
From the Interface Configuration Menu select Ethernet Interface (fei0) sub-menu [E].
2
3 Set Ethernet IP Address [I].
CDM-IP 1 to 172.16.10.1
CDM-IP 2 to 172.17.10.1
4 Set Ethernet Subnet MaskSubnet Prefix Length [M] to 24.

D.3.5 Set IP Stack DES Select Key to ClearRoute Table

Perform the following steps on CDM-IP 1
Step
1 From Transmitter Configuration Main Menu sub-menu select Route Table [R]sub-
menu.
2 Enter 1 to configure the first route.
3 Enter a suitable name.
4 Set IP Address to 172.17.10.0
5 Set Number of Subnet Bits to 24.
6 For Interface to which route is destined to <E-Ethernet S-Satellite Enter : S>
select S.
6 For HDLC address [SMALL NETWORK] in hex <0x1 - 0xFE, enter = 0000>:
select 2.
7 CDM-IP 1 Route Table should display the following:
Route Name
Route001..[test
Perform the following steps on CDM-IP 2
Step
8 From Transmitter Configuration Main Menu sub-menu select Route Table [R] sub-
menu.
9 Enter 1 to configure the first route.
10 Enter a suitable name
11 Set IP Address to 172.16.10.0
Set Number of Subnet Bits to 24
12
Description
Description
Dest IP/SNet Bits
172.17.10.0/24
Description
D–9
Next Hop MultiCast
0x2 N/A
Revision 3
MN/CDM570L.IOM
State
toSat]
