CDM-570 Satellite Modem with Optional IP Module
F.2.3.32 (ODU,ENABLE,1:1,CSAT#1,CONFIG,MISCELLANEOUS)
REF-ADJUST
(ODU,ENABLE,1:1,CSAT#2,CONFIG,MISCELLANEOUS)
REF-ADJUST
(ODU,ENABLE,STAND-ALONE,CONFIG,MISCELLANEOUS)
REF-ADJUST
Internal Ref Adjustment:
087
The user is prompted to edit the Internal 10MHz Reference setting using the ▲ ▼ arrow
keys, then to press ENT. The value will scroll between 000 and 255. NOTE: The
Internal Reference is adjusted in the factory to be very accurate with the default setting of
087. This parameter is made available to compensate for the long-term frequency drift of
the oscillator.
F.2.3.33 (ODU,ENABLE,1:1,CSAT#1,CONFIG,MISCELLANEOUS)
(ODU,ENABLE,1:1,CSAT#2,CONFIG,MISCELLANEOUS)
(ODU,ENABLE,STAND-ALONE,CONFIG,MISCELLANEOUS)RTC
Sync ODU RTC to Lcl RTC:
Yes
The user is prompted to select either Yes or No, using the ◄ ► arrow keys, then to press
ENT. Selecting Yes will cause the CSAT Real Time Clock (RTC) to be synchronized
with the Modem RTC.
F.2.3.34 (ODU,ENABLE,1:1,CSAT#1)
(ODU,ENABLE,1:1,CSAT#2)
(ODU,ENABLE,STAND-ALONE)
INFO: Model Transmitter
Receiver LNA Misc
The operator uses this menu item to select enter 1 of 5 'Information Windows'. Use the
◄ ► arrow keys, then press ENT.
F.2.3.35 (ODU,ENABLE,1:1,CSAT#1,INFO)
(ODU,ENABLE,1:1,CSAT#2,INFO)
(ODU,ENABLE,STAND-ALONE,INFO)
CSAT-5060/010
SERIAL # 00225
This window provides the CSAT Model Number and Serial Number, press ENT.
(▲ ▼,ENT)
◄ ►,
No ( ENT)
(◄ ►)
V2.09
(ENT)
Addendum B- 12
