CDM-570/570L Satellite Modem with Optional IP Module
Web Server Pages
18.2.5

Administrative Database

Any changes made to the IP Module will be lost if the IP Module is reset or loses power
unless the changes are saved to permanent storage. This applies to all of the IP Module
IP parameters. The IP Module parameters can be saved by selecting "Save Parameters
IMPORTANT
to Permanent Storage" on the Maintenance/IP Dbase web page.
All base modem parameters configured via the IP Module (i.e., TX Frequency, data rate,
etc.) and the Ethernet Port Address/Mask will be automatically stored in the CDM-
570/570L base modem non-volatile RAM and will be retained if there is a power loss.
Field
Parameter
Image Load
From
Image Save
To
Select from:
Save Parameters to Flash - When changes are made to the IP Module
protocol system, the Flash Save option must be selected in order for these
settings to be valid through a power cycle. Without using this option,
settings will revert back to their previous state as indicated by the last time
the flash was saved.
Restore Factory Defaults – uses the internal, hard-coded factory default
parameters.
Determines which version of the IP Module Software Package (includes
Application, FPGA, and FFPGA) will be loaded upon boot-up. The
possible options are:
Latest - boot the newest Software Package based upon date.
Image1 - boot the Software Package loaded into the first slot in
permanent storage.
Image2 - boot the Software Package loaded into the second slot in
permanent storage.
Determines which installed Software Package (includes Application,
FPGA, and FFPGA) that the IP Module will overwrite when upgrading with
a new Software Package. The possible options are:
Oldest - overwrite the oldest Software Package based upon date.
Image1 - overwrite the Software Package loaded into the first slot in
permanent storage.
Image2 - overwrite the Software Package loaded into the second slot in
permanent storage.
18–8
Description
Revision 3
MN/CDM570L.IOM
