CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
Option
Number
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
Option Displayed
Type
Hardware 150W BPSU
Hardware 100W BPSU
Hardware RS Codec
Hardware TPC Codec
Hardware TPC/LDPC
Hardware IP Module
Hardware H/W Exp-1
Hardware H/W Exp-2
FAST 2048 kbps
FAST 5000 kbps
FAST 8PSK/8QAM
FAST
FAST S/W Exp-1
FAST Hdr Comp
FAST Data Comp
FAST
FAST
6–63
Code
150 Watt, 48 volt BUC PSU
100 Watt, 24 volt BUC PSU
Future Hardware Expansion 1
Future Hardware Expansion 2
8-PSK and 8-QAM modulation
16-QAM
Future Software Expansion 1
IP QoS
3xDES
Revision 3
MN/CDM570L.IOM
Description
Reed-Solomon Codec
Turbo Product Codec
TPC/LDPC Codec
IP Traffic Module
2048 kbps max data rate
5000 kbps max data rate
16-QAM modulation
IP Header Compression
IP Datagram Compression
IP Quality of Service
IP 3xDES Encryption
