CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
If Spectrum is selected, the following sub-menu will be displayed:
If Data is selected, the following sub-menu will be displayed:
6.8.10

(CONFIG, RX) Eb/No

Eb/No Alarm Point:
02.0 dB
Edit the Eb/No alarm point. This is accomplished by selecting the digit to be edited, using
◄ ►
the
The user should then press ENTER.
The range of values is from 0.1 to 16.0 dB. The user may select a value here, and if the
Eb/No falls below this value, a receive traffic fault will be generated.
6.9

(CONFIG) FRAME (Framing Mode)

Framing Mode:
EDMAC EDMAC-2
Select Unframed, EDMAC or EDMAC-2, using the
ENTER.
The sub-branches available are:
Rx Spectrum:
(◄ ►,ENTER)
Inverted
Select Normal or Inverted, using the
Rx Data Sense:
(◄ ►,ENTER)
Inverted
Select Normal or Inverted, using the
(◄ ►,▲ ▼,ENTER)
arrow keys. The value of the digit is then changed using the
Unframed
(◄ ►,ENT)
Normal
◄ ► arrow keys, then press ENTER.
Normal
◄ ►
arrow keys, then press ENTER.
◄ ►
6–25
Revision 3
MN/CDM570L.IOM
arrow keys.
▲ ▼
arrow keys, then press
