CDM-570/570L Satellite Modem with Optional IP Module
SNMP Interface
19.5.4.1 The TCP Connection Table
The tcpConnTable is a table containing TCP connection-specific information. Each row
contains information about a particular current TCP connection. A row is transient, in
that it ceases to exist when the connection makes the transition to the CLOSED state.
This table is implemented per RFC1213.
19.5.5

UDP Group

This group contains control parameters and statistics for the UDP protocol. This group
contains a UDP table describing the UDP ports in use. This group is implemented per
RFC1213.
19.5.5.1 The UDP Listener Table
The UDP listener table contains information about this entity's UDP end-points on which
a local application is currently accepting datagrams. A row contains information about a
particular current UDP listener. This group is implemented per RFC1213.
19.5.6

EGP Group

This group is not implemented in the agent.
19.5.7

Transmission Group

This group is not implemented in the agent.
19.5.8

SNMP Group

This group provides statistical information regarding the SNMP Protocol. This group is
implemented per RFC1213.
19.6

CDM-IP IP Controller Private MIB

The CDM-570/570L SNMP agent also implements two private MIBs. The IP Controller
MIB (CDM-IP Controller) holds all the security, feature selection, and IP related
parameters and the CDM-570/570L modem MIB (CDM-570/570L ) which contains all
the modem specific parameters. For detailed OID information please refer to the actual
MIB file.
19–9
Revision 3
MN/CDM570L.IOM
