Parameter Descriptions
8-85 Slave Timeout Errors
Range:
0
*
8-88 Reset FC port Diagnostics
Reset all FC port diagnostic counters.
Option:
4 4
[0] Do not reset
*
[1] Reset counter
4.9.7 8-9* Bus Jog
8-90 Bus Jog 1 Speed
Range:
Size
related RPM]
*
8-91 Bus Jog 2 Speed
Range:
Size
related RPM]
*

4.10 Parameters: 9-** PROFIBUS

9-00 Setpoint
Range:
0
*
9-07 Actual Value
Range:
0
*
104
Function:
[0 - 0 ] This parameter shows the number
of slave timeout errors.
Function:
Function:
[ 0 - par. 4-13 Enter the jog speed. Activate this
fixed jog speed via the serial port
or fieldbus option.
Function:
[ 0 - par. 4-13 Enter the jog speed. Activate this
fixed jog speed via the serial port
or fieldbus option.
Function:
[0 - 65535 ] This parameter receives cyclic
reference from a Master Class 2. If
the control priority is set to Master
Class 2, the reference for the
frequency converter is taken from
this parameter, whereas the cyclic
reference is ignored.
Function:
[0 - 65535 ] This parameter delivers the MAV for
a Master Class 2. This parameter is
valid if the control priority is set to
Master Class 2.
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
9-15 PCD Write Configuration
Array [10]
Option:
[0]
[302]
[303]
[312]
[341]
[342]
[351]
[352]
[380]
[381]
[411]
[412]
[413]
[414]
[416]
[417]
[553]
[558]
Function:
Select the parameters to be
assigned to PCD 3–10 of the
telegrams. The number of available
PCDs depends on the telegram
type. The values in PCD 3–10 are
then written to the selected
parameters as data values. Alterna-
tively, specify a standard PROFIBUS
telegram in parameter 9-22 Telegram
Selection.
None
Minimum
Reference
Maximum
Reference
Catch up/slow
Down Value
Ramp 1 Ramp
Up Time
Ramp 1 Ramp
Down Time
Ramp 2 Ramp
Up Time
Ramp 2 Ramp
Down Time
Jog Ramp
Time
Quick Stop
Ramp Time
Motor Speed
Low Limit
[RPM]
Motor Speed
Low Limit [Hz]
Motor Speed
High Limit
[RPM]
Motor Speed
High Limit
[Hz]
Torque Limit
Motor Mode
Torque Limit
Generator
Mode
Term. 29 High
Ref./Feedb.
Value
Term. 33 High
Ref./Feedb.
Value
