VTrak 15200 User Manual
Drive Numbering
Each disk drive in VTrak is identified by a number used for creating and
managing logical drives. VTrak numbers disk drives from left to right. Numbers
are stamped above each drive bay for indentification.
Drive 1
Figure 7. VTrak disk drives are numbered left to right
If you plan to operate your VTrak with fewer than 15 disk drives,
install all 15 Drive Carriers into the enclosure, to ensure proper
airflow for cooling.
Be sure each drive is securely fastened to its carrier. Proper
installation ensures adequate grounding and minimizes vibration.
Do not install drives with fewer than four screws.
Previous array enclosures from Promise required you to latch the
drive carrier handle in order to power the drive. VTrak uses the
handle only to lock the carrier in place.
Caution
Important
Note
14
Drive 15
