VTrak 15200 User Manual
The Create Logical Drive window appears.
Type in a Logical Drive name, select RAID Level and Block Size.
See page 189 for an explanation of these RAID concepts.
3.
If you want to initialize the disk drives in your logical drive, check the Initialize
Logical Drive box. Then select the type of Initialization from the drop-down
menu:
Quick – Erases the Reserve Sector, which contains logical drive information
for this disk drive.
Full – Erases all data on the disk drives.
4.
Select the Free Disks you want to use and click the >> button or double-click
on the disks to move them to the Used Disks field.
•
The available RAID selection depends on which Promise
product you have and the number of disk drives available.
•
The default Block size is 64KB.
•
Promise recommends that you check Initialize Logical Drive.
Notes
104
