Chapter 2: Installation
The VTrak staggers disk drive spin-up in order to equalize power draw during
start-up. After a few moments the Power and FRU LEDs should display Green.
The controller activity light blinks on once per second
There are two LEDs on each Drive Carrier. They report the presence of power
and a disk drive, and the current condition of the drive.
Power/
Drive Status
Activity
Figure 13.VTrak 15200 Drive Carrier LEDs
After a few moments the Power/Activity and Disk Status LEDs should display
Green.
If there is no disk drive in the carrier, the Disk Status LED and the Power/Activity
LED will remain dark.
19
