If you plan to use the mounting rails, follow this procedure to install them:
1.
Attach one end of the rail to the back side of the rack's front post.
2.
Reposition the adjusting screws as needed to fit the rail to the rack properly.
3.
Attach the other end of the rail to the back side of the rack's rear post.
4.
Repeat steps 1 through 3 to attach the other rail.
5.
Square the rails in the rack and tighten the attaching screws.
6.
Set the VTrak onto the rails.
7.
Attach the VTrak to the rack's front posts with the screws provided.
Install Disk Drives
Before using the VTrak you must first populate it with Serial ATA (SATA) disk
drives. You can also use Parallel ATA (PATA) disk drives with the optional PATA-
to-SATA adapters available from Promise Technology. The VTrak 15200 can
support up to fifteen disk drives and provide the RAID configurations listed below.
See page 189 for a complete explanation of RAID on VTrak.
* RAID 1 logical drives work in matched pairs. VTrak
supports up to seven (7) RAID 1 logical drives.
Do not pull or push the handles on the Power Supplies or the
Controller units in order to move the VTrak. Hold the VTrak by the
housing only.
RAID Configuration
RAID 0
RAID 1
RAID 3
RAID 5
RAID 10
RAID 50
Caution
Number of disk drives
Minimum
1
2
3
3
4
6
9
Chapter 2: Installation
Maximum
15
2*
15
15
14
14
