Set Up RS-232 Connection
Figure 10. VTrak 15200 RS-232 connection
Connect the null modem cable between the RS-232 serial connector on the Host
PC and the same connector on the back of the VTrak.
See page 50 for CLU configuration.
PR O M ISE
V T r a k 1 5 2 0 0 C
o n t r o l l e r
T
E
C
H
N
O
L
O
G
Y
, I N
C
.
iSC SI 1
iSC SI 2 Mg mt
Be sure the RS-232 serial port on your Host PC is enabled.
RS-232 Serial
Connector
IOIO I
Important
17
Chapter 2: Installation
