*4
*5
Enter Physical Drive ids and/or id ranges
separated by commas. For example: 1,5,8-15.
Press R to continue after you have finished
selecting Physical Drives.
Your input?>r
3. When you have selected all the physical drives, press R and Enter.
RAID Mode Options:
0 - RAID 0 (Striping)
1 - RAID 1 (Mirroring)
3 - RAID 3 (Parity)
5 - RAID 5 (Parity Distributed)
10 - RAID 10 (Striping/Mirroring)
50 - RAID 50
Please enter RAID mode(0,1,3,5)>5
The prompt displays available RAID modes.
4. Type the RAID mode (level) for your logical drive and press Enter.
Stripe Block Size (4, 8, 16, 32 or 64) in KB?>64
Enter the Logical Drive name>LogDrv1
Enable initialization(y/n)?>y
Full or quick initialization(f/q)?>q
Quick initialization enabled
5. Type the stripe block size, logical drive name, whether you want initialization
and if so, quick or full. Press Enter after each input.
If you chose RAID 1, you will not see a stripe block size. After the last item, a
list of your logical drive specifications displays.
Logical Drive creation information:
Name: LogDrv1
Number of Physical Drives: 3
RAID mode: RAID 5
Stripe block size: 64KB
SMART check: enabled
Create Logical Drive now(y/n)?>y
6. Review the list. If you agree with the list, press Y and Enter. If you disagree
with the list, press N and Enter, then select Create New Logical Drive again.
In order to use this logical drive to read and write data, you must partition
and format it using the Host PC's operating system.
Maxtor 6Y080M0
Maxtor 6Y080M0
59
81 GB
81 GB
Chapter 3: Setup
