3 - RAID 3 (Parity)
5 - RAID 5 (Parity Distributed)
10 - RAID 10 (Striping/Mirroring)
50 - RAID 50
Please enter RAID mode(0,1,3,5,10,50)>50
The Auto Creation tells you how many disk (physical) drives are free and
which RAID modes (levels) are possible.
2. Type the RAID mode you want and press Enter.
The proposed specifications for the new logical drive appear
Logical Drive Auto Creation Information:
Name: LogicalDrive
Number of Physical Drives: 6
RAID mode: RAID 50
Stripe block size: 64KB
SMART check: enabled
Initialization: full
Create Logical Drive now(y/n)?>y
3. If you agree with the specifications, press Y and Enter.
If you disagree, press N and Enter. Then select Create New Logical Drive
(below) and input your own settings.
In order to use this logical drive to read and write data, you must partition
and format it using the Host PC's operating system.

Create New Logical Drive

Use this feature to manually build a logical drive to meet your own requirements
or to use less than the full number of available disk drives. See Chapter 7 for a
discussion of RAID Levels, the number of drives each supports and an
explanation of the available options.
1. Press 2 and Enter to access the Create New Logical Drive feature.
**************Define New Logical Drive**************
Total 3 Physical Drives
*******Physical Drives Selection*******
Id
--------------------------------------------------
3
4
5
Name
Maxtor 6Y080M0
Maxtor 6Y080M0
Maxtor 6Y080M0
145
Chapter 5: Management with the CLU
Size
81 GB
81 GB
81 GB
