Toshiba CTX100-S Programming Manual page 61

To establish communication with Strata CTX
1. Open Internet Explorer and point the browser to
the figure below or click on the CTX WinAdmin desktop icon. If the Internet Connection Wizard
displays, refer to
2. Click Go. The Login screen
displays (shown right).
3. To log into CTX WinAdmin for
the first time, enter administrator
in User Name field and password
in the Password field.
4. Click on the Login button. The CTX
WinAdmin Title screen displays.
5. Click CTX (shown right) to go to the
connection setup screen.
Strata CTX Programming - Part 2: CTX WinAdmin Programming 11/03
Step 2 under "Step 1: Install CTX WinAdmin Software" on page
Step 4: Establish Communication with Strata CTX
http://localhost/Ctmc_Local/Default.htm
Installation
as shown in
3-2.
3-15
