Telephone Button Programming
500 Series Programs
Table 13-37 Programs 579~580 (continued)
Button Sequence
579-10 Central VM Callback
A7  C‚yq
, n,
579-11 CFWD All Call Record
A7 C‚yq
, n,
579-12 CFWD Busy Record
A7 ! C‚yq
, n,
579-13 CFWD No Answer
Record
A7 " C‚yq
, n,
579-14 Direct Call
A7 # C‚yq
, n,
579-15 Retrieve Messages
A7 $ C‚yq
, n,
579-16 Voice Main DN
A7 % C‚yq
, n,
579-17 Length of VM ID
A7 & C‚yq
, n, ,
580 Voice Mail Port Data
$' C‚yq
,
580-00 VM Port DN
C‚yq
n,
580-01 Control Method
A7 C‚yq
, n,
580-02 Send A/D Tone
A7! C‚yq
, n,
580-03 Send B Tone
A7" C‚yq
, n,
580-04 End-to-end
A7# C‚yq
, n, ,
13-90
Value(s)
n = Up to 7 digits
n = Up to 4 digits
(default = 91)
n = Up to 4 digits
(default = 91)
n = Up to 4 digits
(default = 91)
n = Up to 4 digits
(default = 91)
n = Up to 4 digits
(default = 91)
n = Up to 7 digits
(default = 91)
n = 1~10
(default = 91)
C‚yq
n = Up to 5 digits
n = 1. Inband/DTMF
2. SMDI
(default = no value)
n = 1. Enable (default)
2. Disable
n = 1. B Tone
2. No Tone (default)
3. B Tone and Extension
Number
n = 1. Enable (default)
2. Disable
C‚yq
Enter the pilot DN for the centralized voice mail system. If this field is
left blank, the previously stored number will be deleted.
Enter DTMF VM-ID prefix string for calls arriving to voice mail via
"Call Fwd All Calls.
Enter DTMF VM-ID prefix string for calls arriving to voice mail via
"Call Fwd Busy."
Enter DTMF VM-ID prefix string for calls arriving at the voice mail via
"Call Fwd No Answer."
Enter DTMF VM-ID string for a call arriving at the voice mail as a
Direct Call.
Enter DTMF VM-ID string for calls arriving at the voice mail to retrieve
messages.
Use a VM Pilot DN as a transfer destination.
Select the number of characters in VM-ID string.
Assign characteristics of individual voice mail ports.
Enter the DN of an individual VM port. For direct transfer to voice
mail, enter the remote Node ID and Pilot DN.
Note Do not enter a Pilot DN. This feature is available only with
CTX Release 1.3 or higher software and with CTX WinAdmin
Release 1.3 or higher software.
Specify In-band or SMDI integration. Select SMDI for Remote voice
mail.
Select whether Strata CTX sends A or D tone when a station
connecting to voice mail answers or disconnects.
Enable Strata CTX to send B tones in the event of a Blind Transfer
Recall.
Enable Strata CTX to send DTMF tones to voice mail in response to
key presses from a digital telephone.
Strata CTX Programming - Part 3: Telephone Button Programming 11/03
