Profile - Toshiba CTX100-S Programming Manual

Tools and Profile

Profile

Profile
The Programs included in the Profile menu enables you to change GUI display settings in CTX WinAdmin
and change the system IP Address.
Customize
Prerequisite Program:
Customize the look and feel of CTX WinAdmin using this program.
1. From the Program Menu, click
Profile > Customize.
2. Select your customized settings.
3. Click Save Changes.
F
IELD
ASP Idle Time
Back Ground Color
Group Name Color
Label Color
User Management
For information on User Management, refer to Chapter 2
12-2
None
D
ESCRIPTION
CTX WinAdmin is designed to automatically log off any inactive users after the time
set in this field.
Possible values: Maximum = 999 minutes (Default = 120 minutes)
Note Set the ASP Idle time to 999 when using long CTX WinAdmin sessions in a
secure environment.
Select the background Color from the scroll down menu.
Possible values: Aqua, Yellow, Sky Blue, Light Sky Blue, Light Blue, Medium
Spring Green, Light Green, Powder Blue, Light Goldenrod Yellow
(default), Misty Rose, Lavender.
Select the color in which to display the Group Name (see figure above).
Possible values: Black, White, Dim Grey (default), Red, Dark Red, Blue, Indigo,
Navy, Purple, Maroon, Teal, Fuchsin, Dark Green.
Select the color with which to display the field name text.
Possible values: Black (default), White, Dim Grey, Red, Dark Red, Blue, Indigo,
Navy, Purple, Maroon, Teal, Fuchsin, Dark Green.
Strata CTX Programming - Part 2: CTX WinAdmin Programming 11/03
"User Management" on page 3-19.
